AV-NS-2 Akuvox SIP 6 x 2 wire Ports 1 Port RJ45 Network Switch
The Akuvox AV-NS-2 is a 6 Port 2Wire Long Data Transmission Distance Device built to enable IP Devices Connected over 2 core cable and allows for retrofitting IP devices in old buildings and residential environs. It makes for a convenient method to upgrade existing analogue intercom systems, with no need for rewiring. Its super long transmission distance & good compatibility with existing lines makes it fit for most of old buildings.
- Description
- Features and Applications
- Specifications
- Downloads
Description
At a Glance
- Support network and power supply for R20A-2 or C313W-2 through 2-wire cable;
- Support multi-level cascade through 2-wire cable;
- Connects up to 6 pcs of Akuvox 2-wire IP intercom devices;
- Super long transmission distance via 2-wire cable;
- Powerd by 48VDC or 24VDC power supply unit;
- Rail mounting installation;
Applications
Retrofitting:
- Old Buildings
- Villas
- Offices etc.
Physical & Power
- Communication: TCP/IP
- RJ45 port: 1 x RJ45 port, 10/100Mbps adapter
- 2-wire ports: 6 pair
- Working voltage: 48V or 24V
- Status Indicator: 4
- Installation: Rail mounting
- Working temperature: -20℃~+50℃
- Storage temperature: -20℃~+70℃
- Working humidity: 10%~90%
- Dimension: 161 x 90 x 65 (mm)
